A2470
Futuzen
| Quantity: | |
|---|---|
| Items | Spec |
| Display | 24.5”IPS 60Hz |
| Resolution | 1920×1080 |
| Brightness | 250 nits(TYP.) |
| CPU support | Intel 12th Gen or 13th Gen or 14th Gen Core™、 Pentium® Gold and Celeron® Processors，Intel N series ，Meteor Lake、AMD Ryzen 7 5700U/8845HS/7730HS etc. |
| Chipset | Intel H610/12450H/N100/N95 |
| M/B Form Factor | Thin mini-ITX 170x170mm |
| Memory | 2x DDR4 memory slots (SO-DIMM), support up to 64GB (3200MHz max) |
| SSD | M.2 2280 64G/128G/256G/512G/1T (SATA/NVME mode) |
| HDD | Supports 1 hard disk with SATA3.0 port 2.5 inches（Quick remove hard drive） （optional） |
| Wifi | M.2/2230 Wi-Fi 5.0/802.11ac Wi-Fi and Bluetooth 4.2 or M.2/2230 Wi-Fi 6.0/802.11ax Wi-Fi and Bluetooth 5.2 |
| Audio | 4Ω3W Speaker×2 |
| Camera | Optional pull-up privacy camera 2M/5M,AMIC*2(Built in camera module) |
| I/O Ports | Rear:USB3.2 Gen1 Type A×4,HDMI out×1,COM/VGA×1,RJ45×1,3.5mm MIC jack ×1,3.5mm Headphone jack ×1（Change according to main board） Side:USB2.0 Type A ×2,USB2.0 Type C×1,3.5mm combo audio jack×1,HDMI in×1（optional） |
| User control | Power、Brightness+、Brightness-、Screen on/off、Display switch |
| Operating System | Windows 11 |
| Power supply | External adapter(60W-120W) |
| Stand Base | Tilt-5° to 20°、High Adjustable Arm 130mm、Left and Right 60°Horizontal Swivel、90°Vertical Swivel |
| VESA Mount | 100*100 |
